Overview
1x DPA 4017C-R Compact Shotgun Mic with Rycote Windshield
DPA Microphones has joined forces with Rycote to develop the DPA 4017C-R Shotgun/Rycote Windshield Solution. The strong suspension and windshield solution has been designed specifically to take the DPA 4017C shotgun mic’s exceptional compact size and lightweight into consideration. This kit provides everything a boomer, outside broadcaster, journalist or location film maker could need for clear, directional sound, regardless of the weather and environmental conditions.
DPA 4017C Short Shotgun:
Setting new standards for compactness within shotgun microphones and their applications, the modular 4017C is an exceptionally short and lightweight interference tube microphone with high directionality. The tight polar pattern is very frequency linear and uniform. With the compact MMP-C pre-amp, booming applications such as in a car or in low ceiling rooms is uncomplicated. The total length of the microphone is as short as 15.4 cm (6.1 in), the weight at just 70 g (2.5 oz).
Specifications
Operating Principle | Pressure Gradient |
Capsule | Condenser |
Diaphragm | 0.75" / 19 mm |
Polar Pattern | Supercardioid |
Frequency Range | 20 Hz to 20 kHz |
Signal to Noise Ratio | 80 dB A-Weighted |
Equivalent Noise Level | 13 dB A-Weighted 24 dB ITU-R 468 |
Maximum SPL | 138 dB SPL |
THD | < 1% |
Impedance | 150 Ohms |
Load Impedance | 2 kOhms |
Sensitivity | -34.4 dB at 1 kHz |
Low-Cut Filter | 4 dB/Octave @ 8 kHz 4 dB/Octave @ 50 Hz 4 dB/Octave @ 120 Hz |
CMRR | 40 dB |
Dynamic Range | 119 dB |
Output Connectors | 1 x 3-Pin XLR |
Operating Current Consumption | 4.5 mA |
Operating Voltage | 1.8 V 48 V ± 4 V |
Operating Temperature | 14 to 113°F / -10.00 to 45.00°C |
Operating Humidity | 90 |
Length | 8.35" / 212 mm |
Diameter | 0.75" / 19 mm |
Weight | 2.40 oz / 68 g |
