Overview
4BAR USB is a complete washlighting solution for mobile entertainers. D-Fi USB compatible for wireless master/slave or DMX control, it also includes a wireless footswitch that can control multiple units. Create synchronized light shows using built-in automated programs with the optional IRC-6 remote.
Features
- Complete wash lighting solution designed for mobile entertainers
- Out of the box wireless control with included footswitch that controls multiple units
- Achieve total room or stage coverage with 4 individually adjustable heads
- D-Fi USB compatibility for wireless master/slave or DMX control
- Easily set-up and tear down in minutes using the included tripod, wireless footswitch and carry bags
- Increase mounting options by safely mounting to truss using the built-in bolts
- Create large, coordinated light shows with other 4BAR fixtures in master/slave mode
- Sound-activated programs dance to the beat of the music
- Easily control static colors and automated programs with the optional IRC-6 remote
- Generate a synchronized show in master/slave mode with easy-to-access, built-in automated programs
Specifications
| DMX Channels | 3 or 15 |
| DMX Connectors | 3-pin XLR |
| Light Source | 432 LEDs (144 red, 144 green, 144 blue) 0.25 W, (20 mA), 100,000 hours life expectancy |
| Strobe Rate | 0 to 20 Hz |
| PWM Frequency | 1.2 kHz |
| Beam Angle | 21° |
| Field Angle | 33° |
| Illuminance | 725 lux @ 2 m (per pod) |
| Input Voltage | 100 to 240 VAC, 50/60 Hz (auto-ranging) |
| Power and Current | 36 W, 0.6 A @ 120 V, 60 Hz 36 W, 0.3 A @ 230 V, 50 Hz |
| Weight | 10.8 lb (4.9 kg) (Controller): 0.8 lb (1.8 kg) |
| Size | 47.4 x 2 x 11 in (1,205 x 50 x 285 mm) (Controller): 12.4 x 5.2 x 1.5 in (315 x 132 x 38 mm) |
| Approvals | CE |
| Optional Controllers | IRC-6, D-Fi USB |
| Stand Height | 7 ft 4 in (2.2 m) |
